Fender Quantum LT 16 USB-C Audio Interface
The Fender Quantum LT 16 USB-C Audio Interface is the powerhouse your project studio has been waiting for. Designed to deliver exceptional clarity and flexibility, this interface lets you record a wide variety of projects. From large ensembles to multi-instrument setups to electronic music.
Capture Every Detail with MAX-HD Mic Preamps
Firstly, with eight MAX-HD mic preamps offering a stunning 75 dB of gain, the LT 16 ensures your recordings are pristine. Whether you’re miking a full drum kit or multiple vocalists, each track shines with the natural, transparent sound.
Unleash Your Creativity with Extensive Connectivity
Moreover, the LT 16 features 14 TRS analog line inputs, including six on the front and eight on the rear. Therefore, letting you seamlessly connect synthesizers, mixers, external mic pres, and other line-level devices. Balanced TRS outputs and a powerful headphone amp offer reliable, professional-grade monitoring options for any setup.
Versatile Features for Studio and Live Use
Transform the LT 16 into an 8-channel standalone mic preamp with “Mic Pre Mode,” expand your modular synth setup using DC-coupled outputs, and integrate hardware seamlessly with 5-pin MIDI I/O. Included with the interface is Fender Studio Pro, a professional DAW with exclusive Mustang and Rumble amp plug-ins, giving you an all-in-one creative package.
- 16 x 8 USB-C Interface with ultra-low-latency custom drivers for macOS and Windows
- Eight MAX-HD mic preamps with 75 dB gain for transparent, low-noise recording
- 14 TRS analog line inputs for extensive connectivity with outboard gear
- Dual Fender-designed instrument inputs optimized for guitars and basses
- 16 x 8 USB-C Interface with ultra-low-latency custom drivers for macOS and Windows
- Eight MAX-HD mic preamps with 75 dB gain for transparent, low-noise recording
- 14 TRS analog line inputs for extensive connectivity with outboard gear
- Dual Fender-designed instrument inputs optimized for guitars and basses
- Balanced TRS outputs and powerful headphone amp for professional monitoring
- Standalone “Mic Pre Mode” to use as an 8-channel mic preamp
- DC-coupled outputs for integrating modular synths and analog gear
- 5-pin MIDI I/O for hardware integration without external interfaces
- Fender Studio Pro perpetual license included with exclusive Mustang and Rumble plug-ins
*]:pointer-events-auto scroll-mt-[calc(var(–header-height)+min(200px,max(70px,20svh)))]” dir=”auto” tabindex=”-1″>
Microphone Inputs
Connection Type: XLR Female (Combo), Balanced
Frequency Response: 20 Hz to 20 kHz
Dynamic Range: 115 dB
EIN: -128.6 dBu
THD+N: 0.001 %
Gain Range: 75 dB
Maximum Input Level: +18 dBu
Phantom Power: +48 VDC
Line Inputs
Connection Type: 1/4″ TRS Female
Frequency Response: 20 Hz to 20 kHz
Dynamic Range: 115 dB (+4 dBu) / 113 dB (-10 dBV)
THD+N: 0.001 % (+4 dBu) / 0.0009 % (-10 dBV)
Maximum Input Level: +18 dBu
Instrument Inputs
Connection Type: 1/4″ TS
Frequency Response: 20 Hz to 20 kHz
Dynamic Range: 114 dB
THD+N: 0.003%
Maximum Input Level: +22 dBu
Line Outputs
Connection Type: 1/4″ TRS Female
Maximum Output Level: +18 dBu
Main Outputs
Connection Type: 1/4″ TRS Female
Headphone Outputs
Connection Type: 1/4″ TRS Female
Frequency Response: 20 Hz to 20 kHz
Dynamic Range: 114 dB
THD+N: 0.01 %
Maximum Output Level: 142 mW/Channel (60Ω Load)
MIDI I/O
Connection Type: 5-Pin Female DIN
Power
Voltage: 120V
Power Requirements: 100–240 VAC, 50–60 Hz
Digital Audio
Connectivity: USB-C
Bit Depth: 24 Bit
Dynamic Range: 115 dB
Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
Measurements
Height: 1.75″ (44.45 mm)
Depth: 5″ (127 mm)
Width: 19″ (483 mm)
Weight: 4.8 lbs (2.2 kg)
General
Color: Black
